Specifications
Connection type
Angle connection
Material
Die-cast
Weight/piece
23 g
Groove size
6 mm
Dimension A
30 mm
Dimension B
30 mm
Dimension C
30 mm
Dimension D
5 mm
Business division
MUNK Profiltechnik
Order no.
930207
Information
- Profile angle for profile 30
- For joining profiles to each other
- Particularly suitable for retrofitting profiles
Secure 90° connections for modular construction kits – optionally for groove 6 in 30 mm profiles or groove 8 in 40 mm profiles.
Key advantages
- Universally applicable: Suitable for all MUNK construction profiles 30 × 30 mm (groove 6) or 40 × 40 mm (groove 8) – ideal for right-angled frames, racks and protective enclosures.
- Easy to retrofit: Can be swivelled into open grooves; perfect for extensions without dismantling entire assemblies.
- Robust & durable: Die-cast body with 5 mm wall thickness for high clamping forces and permanent angle stability.
- Clean appearance: Internal screws conceal fastening points and ensure smooth outer surfaces.
Typical applications
- Machine frames: Reinforcement of 30 or 40 mm profiles without welding.
- Protective and test enclosures: Quick assembly of stable 90° frames with glass or mesh panels.
- Assembly tables and workstations: Retrofitting of shelves, guide plates or swivel arms.
- Transport racks: Torsion-resistant corner connections for tow tractors and load carriers.
Assembly instructions
Insert or swing in the groove nut (not included), attach the corner bracket, tighten the screw (not included) with an Allen key – done. The connection remains detachable and can be moved or extended at any time.
- Profile angle for profile 30
- For joining profiles to each other
- Particularly suitable for retrofitting profiles
Scope of supply
- Corner bracket: 1 x
Comparison table
| Product name | Corner bracket 30x30 mm Profile 40 | Corner bracket 40x40 mm Size 8 Profile 40 |
|---|---|---|
| Connection type | Angle connection | Angle connection |
| Material | Die-cast | Die-cast |
| Weight/piece | 23 g | 59 g |
| Groove size | 6 mm | 8 mm |
| Dimension A | 30 mm | 40 mm |
| Dimension B | 30 mm | 40 mm |
| Dimension C | 30 mm | 40 mm |
| Dimension D | 5 mm | 5 mm |
| Business division | MUNK Profiltechnik | MUNK Profiltechnik |
| Order no. | 930207 | 930205 |
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
